DRAINING THE CARBURETOR
After each use, open up the carburetor drain with a screwdriver and drain
out any gasoline that has built up inside. Once the fuel has drained, close
the drain back up with the same screwdriver. It is best to do this after
every use and required before storing the generator for long periods of
time. The location of the carburetor can be found in Fig. 12.
19
DC Output
USB Charger 5V, 1A (left) / 5V, 2.1A (right)
AC Output
Rated Wattage 1000 Watts
Surge Wattage 1250 Watts
Rated Voltage 120V
Rated Amperage 8.3A
Frequency 60 Hz
Phase Single
Engine
Engine type 4 stroke, OHV, single cylinder with forced air cooling system
Spark plug gap 0.6 - 0.8 mm (0.024 - 0.031 in)
Spark plug torque 1/2 - 3/4 turn after gasket contacts base or 9.2 ft.lb
Displacement 60cc
Fuel tank capacity 0.69 gallons (2.6 L)
Oil capacity 0.27 quarts (310 mL)
Lubrication system Splash lubrication
Run time on 50% load 5 hours
Spark plug A5RTC
SPECIFICATIONS
MAINTENANCE & CARE
Carburetor
Fig. 12
