21
SPECIFICATIONS
DC output
Rated Voltage 12 VDC
Rated Amperage 8.3 A
Rated Wattage 100 W
USB Charger 5V, 1 A
AC output
Rated Wattage 1600 Watts
Surge Wattage 2000 Watts
Rated Voltage 120 V
Rated Amperage 13.3 A
Frequency 60 Hz
Phase Single
Dimensions
Length: 20.50 inches
Width: 11.60 inches
Height: 19.30 inches
Weight 48.4 lbs
Engine
Engine type 4 stroke, OHV, single cylinder with forced air cooling system
Spark plug gap 0.6 - o.7 mm (0.024 - 0.028 in)
Spark plug torque 1/2 - 3/4 turn after gasket contacts base or 15 ft.lb
Displacement 79.7 cc
Fuel tank capacity 1 gallon 87 octane minimum
Oil capacity 0.37 quarts (0.35 liters)
Lubrication system Splash lubrication
Run time on 50% load 4 hours
Noise rating 63 dB at 22 feet
Spark plug A5RTC
