No. Part No. Name Qty
60 56207-060 Bolt 6
61 56207-061 Spring Washer 9
62 56207-062 Washer 9
63 56207-063 Gear Pump Cover 1
64 56207-064 Spring 2
65 56207-065 Gear Housing Plate 1
66 56207-066 Circlip 2
67 56207-067 Gear Shaft 1
68 56207-068 Steel Ball 1
69 56207-069 Gear 2
70 56207-070 Pin 1
71 56207-071 Washer 6
72 56207-072 Bolt 3
73 56207-073 Motor Cover 1
74 56207-074 Seal 1
75 56207-075 Nut 1
76 56207-076 Screw 1
77 56207-077 Motor 1
78 56207-078 Fan 1
79 56207-079 Block turn 1
80 56207-080 Shroud 1
81 56207-081 Spring Washer 6
82 56207-082 Screw 2
83 56207-083 Leg 1
84 56207-084 Nut 5
85 56207-085 Bolt 5
86 56207-086 Cable & plug 1
88 56207-088 Cable Grommet 1
No. Part No. Name Qty
90 56207-090 Screw 11
91 56207-091 Switch Box cover 1
92 56207-092 Airproof underlay 1
93 56207-093 Connection Terminal 1
94 56207-094 Capacitor 1
95 56207-095 Switch 1
96 56207-096 Switch Box 1
97 56207-097 Waterproof Seal 1
98 56207-098 Motor Support Left Shoe 1
99 56207-099 Motor Support Right Shoe 1
100 56207-100 Pin 2
101 56207-101 Spring 2
102 56207-102 Sliding Sleeve 4
103 56207-103 Bolt 3
104 56207-104 Cotter Pin 2
105 56207-105 Washer 2
106 56207-106 Wheel Bracket 1
107 56207-107 Bolt 6
108 56207-108 Nut 6
109 56207-109 Washer 6
110 56207-110 Spring Washer 6
111 56207-111 Front Stand Leg 1
112 56207-112 Bolt 4
113 56207-113 Stand Connection Member 1
114 56207-114 Rear Stand Bottom 1
115 56207-115 Rear Stand Legs 2
116 56207-116 Ram Limiting Ring 1
117 56207-117 Star Handle 1
EXPLODED VIEW & PARTS LIST
