HARDWARE BAG
1. M10 x 25 Bolts (x4)
2. M8 x 25 Bolts (x6)
3. M8 Nuts (x6)
4. Spring Washers (x6)
5. Washers (x6)
Log Ram
Hydraulic Lever
Log Cradle
ON/OFF Push Button
Circuit Breaker
Motor
Main Beam
Log Wedge
Lift Handle
Bleed Screw
Ram Limiting Ring
Fluid Drain Bolt
with Dipstick
LOG SPLITTER SAFETY WARNINGS
WARNING! Do not operate the power tool until you have read and understood the following instructions and
the warning labels.
11. Never use your hands to remove a jammed
log. If a jam should occur, release the on/off push
button. Follow the instructions in this manual for
removing a jammed log.
12. Securely stack the split logs to provide a safer,
less cluttered work area.
MAINTAINING THE LOG SPLITTER
1. Disconnect the log splitter from its power
source before making adjustments or repairs.
2. When servicing, use only identical replacement
parts. Connection and repair work on the electrical
installation should only be carried out by a trained
professional.
KNOW YOUR LOG SPLITTER
7
