Wen 56235i User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 56202i-101
Hex Head Flange Bolt,
M6x18
4
2 56202i-102
Spark Plug, Torch E5T
(NGK BP5H)
1
3 56202i-103 Breather Tube 1
4 56202i-104
Cylinder Head Cover As-
sembly
1
5 56202i-105
Strainer, Cylinder Head
Cover
1
6 56202i-106
Inner Cover, Cylinder Head
Cover
1
7 56202i-107 Cross Head Screw, M3x6.5 3
8 56202i-108
Gasket, Cylinder Head
Cover
1
9 56202i-109 Rocker Arm Assembly 2
10 56202i-110 Shaft, Rocker Arm 1
11 56202i-111 Valve Collet 2
12 56202i-112 Oil Drip Plug 1
13 56202i-113 Valve Spring Seat, 182F 2
14 56235i-114 Spring Valve 2
15 56202i-115 Flange Bolt, M6x50 4
16 56235i-116 Cylinder Head 1
17 56202i-117 Stud Bolt, M6x72 2
18 56202i-118 Gasket, Muffler 1
19 56203i-119 Exhaust Muffler Assembly 1
20 56202i-120 Flange Bolt M6x60 4
21 56202i-121 Lock Nut M6, Flange 4
22 56202i-122 Stud Bolt, M6x87 2
23 56202i-123 Gasket, Carburetor 1
24 56202i-124 Insulator, Carburetor 1
25 56202i-125 Gasket, Insulator 1
26 56235i-126 Carburetor 1
27 56202i-127 Stepper Motor 1
28 56203i-128 Screw, M4x6 2
29 56202i-129 Clamp 1, Ø7.5 1
30 56202i-130 Oil Tube 1
31 56202i-131 Air Filter Hose 1
32 56202i-132 Clamp 1
33 56202i-133 Gasket, Cylinder Head 1
34 56202i-134 Dowel Pin, Ø8x12 4
NO. PART NO. DESCRIPTION QTY.
35 56202i-135 Push Rod 2
36 56202i-136 Valve, Exhaust 1
37 56235i-137 Valve, Intake 1
38 56202i-138 Lifter, Valve 2
39 56202i-139 Piston Ring Set 1
40 56202i-140 Circlip 2
41 56202i-141 Piston Pin 1
42 56235i-142 Piston 1
43 56202i-143 Connecting Rod Assembly 1
44 56202i-144 Crankcase 1
45 56202i-145 Oil Level Sensor 1
46 56202i-146
Hex Head Flange Bolt,
M6x16
2
47 56202i-147
Hex Head Flange Bolt,
M6x12
5
48 56202i-148 Crankshaft 1
49 56235i-149 Camshaft 1
50 56202i-150 Gasket, Crankcase Cover 1
51 56202i-151 Cover, Crankcase 1
52 56202i-152
Hex Head Flange Bolt,
M6x20
7
53 56202i-153 Oil Dipstick Assembly 1
54 56202i-154 Trigger 1
55 56202i-155 Oil Seal, Ø20xØ32x6 1
56 56235i-156 Alternator Assembly 1
57 56202i-157 Flange Bolt, M6x32 2
58 56202i-158 Cooling Fan 1
59 56202i-159 Pulley, Starter 1
60 56202i-160 Flange Nut, M12-1.25 1
61 56202i-161 Fan Cover Assembly 1
62 56202i-162 Fan Cover 1
63 56202i-163 Air Filter Element 1
64 56202i-164 Air Filter Cover 1
65 56202i-165 Wire Clip B 1
66 56202i-166 Recoil Starter Assembly 1
67 56202i-167
Hex Head Flange Bolt,
M6x14
3
68 56202i-168 Lock Nut 2
ENGINE
34

Wen 56235i Specifications

General

Model	Wen 56235i
Category	Portable Generator
Running Watts	1900W
Starting Watts	2350W
Engine	79.7cc 4-stroke OHV
Fuel Type	Gasoline
Tank Capacity	1 Gallon
Noise Level	51 dB
Inverter	Yes
Starting System	Recoil
Rated Voltage	120V
Rated Frequency	60 Hz
Max Output	2350W
Weight	39 pounds
Outlets	1x 12V DC
DC Output	12V, 8.3A
Run Time at 50% Load	6 hours
