EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 56203i-005.1
NEMA 5-20R 120V AC
Duplex Outlet
1
2
56203i-005.2 DC 12V Outlet 1
3
56203i-005.3 USB Outlet 1
4
56203i-005.4 Eco-Mode Switch 1
5
56203i-005.5 Reset Button 1
6
56203i-005.6 DC Breaker, 8A 1
7
56203i-005.7 Oil Level LED, Yellow 1
CONTROL PANEL
36
NO. PART NO. DESCRIPTION QTY.
8
56203i-005.8 Overload LED, Red 1
9
56203i-005.9 Output LED, Green 1
10
56203i-005.10 Nut, M6 2
11
56203i-005.11 Locking Washer, 6mm 2
12
56203i-005.12 Flat Washer, 6mm 2
13
56203i-005.13 Bolt, M6x20 1
14
56203i-005.14 Parallel Socket 2
15
56203i-005.15 Washer, 6mm 1
