Wen 56235iX

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
10 56202i-010 Fuel Valve 1
11 56202i-011
Hex Head Flange Bolt,
M6x14
2
12 56235i-012 Clamp 1, Ø7.5 2
13 56203i-013 Big Flange Bolt, M6x12 13
14 56235iX-014 Inverter, 120V 60Hz 1
15 56235i-064 Spring 1
16 56235iX-016 Engine Assembly, 79cc 1
17 56202i-017 Bolt, M5x12 1
18 56202i-019 Front Air Guide 1
19 56203i-019
Self-tapping Screw,
ST4.2x25
4
20 56202i-020 Threaded Clamp 12
21
56235iX-
021ASM
Left Frame Assembly 1
22 56202i-022 Shaft Locating Bolt 6
23 56202i-023 Left Cover Panel 1
24 56202i-024
Protective Panel, Starter
Handle
1
25 56202i-025 Screw, M5x16 4
26 56202i-026 Tube Sheath 1
27 56202i-027 Fuel Tube, 300mm 1
28 56202i-028 Clamp 2, Ø9.7 x 8 1
29 56202i-029 Fuel Strainer 1
30 56202i-030 Rubber Pad 2
31 56203i-031 Fuel Tank 1
32 56202i-032 Rubber Washer 1
33 56202i-033 Lock Nut 1
34 56202i-034 Fuel Tank Cap 1
35 56202i-035 Muffler Cover 1
36 56202i-036 O-ring Seal 1
37 56202i-037 Retainer Ring 5
38 56202i-038
Self-tapping Screw,
ST4.2x9.5
1
39 56202i-039 Spark Arrestor Assembly 1
40 56202i-040 Rear Air Guide 1
41 56202i-041 Oil Seal 1
GENERATOR
33
NO. PART NO. DESCRIPTION QTY.
42 56202i-042 Ignition Coil 1
43 56202i-043
Self-tapping Screw,
ST4.8x20
2
44
56202i-
044ASM
Right Frame Assembly 1
45 56202i-045 Spark Plug Access Panel 1
46 56235iX-046 Igniter 1
47 56235iX-047 Right Cover Panel 1
49 56235iX-049 Phillips Screw 4
50 56202i-050 Oil Access Panel 1
51 56203i-051 Screw, M6x12 3
52 56202i-052 Rectifier Bridge 1
53 56202i-053 Damper Supports 4
54 56202i-054 Rubber Support 1
55 56202i-055 Bottom Plate Assembly 1
56 56202i-056 Nut M6 4
57 56202i-057 Foot 4
58 56203i-058 Bolt, M6x18 2
59 56203i-059 Clip 1
60 56203i-021 Left Frame 1
61 56202i-044 Right Frame 1
62
56202i-
055.1
Base Plate 1
63 56235i-063
Self-tapping Screw,
ST4.2x10
2
64 56235iX-064 Block 1
65 56203i-065 Rubber Ring 1
66 56203i-066 Cover Plate 1
67 56235iX-067 CO Sensor Bracket 1
68 56235iX-068 CO Sensor Module 1
69 56235iX-069 Screw, M5x12 2
