3938
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 P54237 Frame 1
2 P54242
Bottom Rubber
Damper A
2
3 P54244
Bottom Rubber
Damper B
2
4 P54246 Nut, M8 8
5 P54871 Rubber Foot Assembly 4
5
5
5
5
4
4
4
4
1
4
4
4
4
2
2
3
3
ASSEMBLY 16 - ENGINE FRAME
No. Part No. Description Qty.
4 P54051 Cylinder Head Gasket 1
5 P54066
Cylinder Head Cover
Assembly
1
6 P54064
Cylinder Head Cover
Gasket
1
7 P54043 Air Duct 1
8 P54040 Bolt, M6x12 4
9 P54047 Stud 2
10 P54058 Stud 2
11 P54048 Pin 2
12 P54062 Bolt 4
13 P54060
Spark Plug, Torch
F7TC (NGK BP7ES)
1
14 P54054
Cylinder Head
Assembly
1
ASSEMBLY 17 - CYLINDER HEAD
8
56
13
4
7
12
14
10
9
11
To Next Page
