Wen 56477i User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
21 56477i-121
Bushing,
12x16.8-8.5x6.5
1
22 56477i-122 Crankcase Cover 1
23 56477i-123 Crankcase Gasket 1
24 56477i-124 Pin, 8x14 2
25 56360iX-070 Bearing, TM6205 2
26 56477i-126 Crankshaft 1
27 56477i-127 Camshaft 1
28 56477i-128 Woodruff Key 1
29 56477i-129 Valve Cover Cushion 1
30 56477i-130 Bolt, M6x10 2
31 56477i-131 Cylinder Head Plastic Cover 1
32 56477i-132 Dipstick Drip Guard 1
33 56477i-133 Bolt, M6x25 4
34 56477i-134 Bolt, M6x16 3
35 56477i-135 Cylinder Head Cover 1
36 56477i-136 Valve Cover Plate 1
37 56477i-137 Bolt, M5x10 1
38 56477i-138 Ignition Coil 1
39 56477i-139 Engine Cowling, Right 1
40 56477i-140 Valve Cover Plate Gasket 1
41 56477i-141 Rocker Arm Assembly 2
42 56477i-142 Rocker Arm Base 1
43 56477i-143 Valve Spring Seat 2
44 56477i-144 Valve Spring 2
45 56477i-145 Intake Valve Seal 1
46 56477i-146 Valve Adjustment Cap 2
47 56477i-147 Valve Locker 4
48 56477i-148 Clip Base 1
49 56477i-149 Cylinder Head Cover Gasket 1
50 56360iX-015 Bolt, M8x60 4
51 56477i-151 Cylinder Head 1
52 56477i-152 Cylinder Head Gasket 1
53 56360iX-085
Pin, ф10x16
2
54 56477i-154 Exhaust Valve 1
55 56477i-155 Intake Valve 1
56 56477i-156 Push Rod 2
57 56360iX-038 Valve Tappet 2
58 56477i-158 Piston Ring Set 1
ENGINE
NO. PART NO. DESCRIPTION QTY.
59 56477i-159 Circlip 2
60 56477i-160 Piston 1
61 56477i-161
Connecting Rod
Assembly
1
62 56477i-162 Piston Pin 1
63 56477i-163
Spark Plug, LG F6RTC
(NGK BPR6ES)
1
64 56477i-164 Stud 3
65 56477i-165 Muffler Assembly 1
66 56477i-166 Nut, M6 5
67 56477i-167 Muffler Gasket 1
68 56477i-168
Grounding Bolt,
M10-1.25x15)
2
69 56477i-169 Washer, 10 x 1.5 x 16 2
70 56477i-170 Grounding Wire 1
71 56477i-171 Bolt, M6x16 6
72 56477i-172 Oil Sensor 1
73 56477i-173 Bolt, M6x22 4
74 56477i-174 Gasket, Wire 1
75 56477i-175 Crankcase 1
76 56477i-176 Trigger 1
77 56360iX-093 Bolt, M6x12 2
78 56360iX-055 Oil Seal, 25x41.25x6 1
79 56477i-179 Stator Assembly 1
80 56477i-180 Bolt, M6x53 3
81 56477i-181 Rotor 1
82 56477i-182 Cooling Fan 1
83 56477i-183 Starter Cup 1
84 56477i-184 Nut, M14-1.5 1
85 56477i-185 Stud 2
86 56477i-186 Blower Housing 1
87 56477i-187 Stud 2
88 56360iX-066 Recoil Starter 1
89 56477i-189
Self-tapping Screw,
ST4.2x9.5
1
90 56477i-190 Engine Cowling, Left 1
91 56477i-191 Dipstick 1
92 56477i-192 Dipstick Seat Assembly 1
N.P. 56477i-HA39
High-Altitude Kit,
3000 - 9800 ft
N/A
34
