Wen 6500

13
EXPLODED VIEW AND PARTS LIST
No. Part Number Description Qty.
1 6500-001 Pan Head Screw 6
2 6500-002 Lock Washer 6
3 6500-003 Flat Washer 6
4 6500-004 Bearing House 1
5 6500-005 Ball Bearing 2
6 6500-006 Abrasive Belt 1
7 6500-007 Drive Drum 1
8 6500-008 Work Stop 1
9 6500-009 Sanding Belt Plate 1
10 6500-010 Carriage Bolt 2
11 6500-011 Bearing House 1
12 6500-012 Hex Nut 2
13 6500-013 Support Rod 1
14 6500-014 Spring 1
15 6500-015 Sliding Support 1
16 6500-016 Tracking Adjust Knob 1
17 6500-017 Tension Lever 1
18 6500-018 Hex Head Bolt 1
19 6500-019 Spring 1
20 6500-020 Retaining Ring 2
21 6500-021 Idle Drum Shaft 1
22 6500-022 Ball Bearing 2
23 6500-023 Idle Drum 1
24 6500-024 Socket Head Screw 2
25 6500-025 Support Block 1
26 6500-026 Body 1
27 6500-027 Switch Plate 1
28 6500-028 Switch 1
29 6500-029 Pan Head Screw 3
30 6500-030 Lock Washer 1
31 6500-031 Serrate Washer 1
32 6500-032 Holding Plate 1
33 6500-033 Hex Nut 2
34 6500-034 Set Screw 1
35 6500-035 Idle Pulley 1
36 6500-036 V Belt 1
37 6500-037 Belt Cover 1
38 6500-038 Set Screw 1
39 6500-039 Aluminum Disc 1
40 6500-040 Abrasive Disc 1
41 6500-041 Hex Head Bolt 2
42 6500-042 Flat Washer 2
No. Part Number Description Qty.
43 6500-043 Pan Head Screw 1
44 6500-044 Flat Washer 1
45 6500-045 Flat Washer 1
46 6500-046 Lock Washer 1
47 6500-047 Hex Nut 1
48 6500-048 Hex Head Bolt 2
49 6500-049 Flat Washer 2
50 6500-050 Bushing 1
51 6500-051 Strain Relief Mounting Plate 1
52 6500-052 Flat Washer 2
53 6500-053 Pan Head Screw 2
54 6500-054 Strain Relief 1
55 6500-055 Power Cord 1
56 6500-056 Suppopt Plate 1
57 6500-057 Motor 1
58 6500-058 Hex Head Bolt 4
59 6500-059 Flat Washer 8
60 6500-060 Hex Nut 4
61 6500-061 Motor Pulley 1
62 6500-062 Set Screw 1
63 6500-063 Base 1
64 6500-064 Foot 4
65 6500-065 Flat Washer 4
66 6500-066 Hex Head Bolt 4
67 6500-067 Hex Nut 1
68 6500-068 Table Support Rod 1
69 6500-069 Set Screw 2
70 6500-070 Pivot Bracket 1
71 6500-071 Hex Head Bolt 1
72 6500-072 Flat Washer 1
73 6500-073 Flat Washer 1
74 6500-074 Knob 1
75 6500-075 Angle Plate 1
76 6500-076 Pan Head Screw 1
77 6500-077 Pointer 1
78 6500-078 Table Mounting Rod 1
79 6500-079 Table 1
80 6500-080 Miter Guage 1
81 6500-081 4mm Hex Wrench 1
82 6500-082 3mm Hex Wrench 1
83 6500-083 Spanner 1
