UNPACKING
A - Belt Sander
B - Work Stop
C - Support Rod with Nut
D - Table Assembly
E - Miter Gauge
F - Aluminum Disc
G - Abrasive Sanding Disc
H - Foot (4)
I - Hex Wrench (2)
J - Spanner (1)
A
B
C
D
E
F
G
H
I
J
UNPACKING
WARNING: To avoid injury from accidental startups, turn switch OFF and remove the plug from the
power source outlet before making any adjustments.
Carefully unpack the belt/disc sander and all its parts, and compare against the list below. Do not discard the
carton or any packaging until the belt/disc sander is completely assembled.
7
KNOW YOUR BELT/DISC SANDER
Abrasive
Sanding Belt
Belt Tracking
Adjustment Knob
Belt Tension
Release Lever
Table
Table
Angle Scale
Work Stop
Horizontal to Vertical
Pivot Hex Nuts
Power
Switch
Abrasive
Sanding Disc
