18
EXPLODED VIEW AND PARTS LIST
Item # Stock # Description
47 90228-040
Screw M5x20
48 6502-048 Bushing
49 6502-049 Connection Rod
50 6502-050 Extension Spring
51 6502-051 Belt Tension Knob
52 6502-052 Big flat washer D5
53 90228-046 Hex Bolt M6x20
54 90228-047 Screw M5x16
55 90228-048 Adjust Knob
57 90228-050 Rubber Washer
58 90228-051
Adjust Spring
59 90228-052
Belt Support
60 90228-053
Work Rest
61 90228-084
Driving Roller Assembly
62 6502-062 Screw M8x12
63 6502-063 Driving Pulley Shaft
64 90228-054
Bearing Cap
65 90228-055
Support Cover
66 90228-056 Screw M5x10
67 90228-057
Cog Belt Guard Cover
68 90228-058
Screw M5x16
69 90228-059
Special Locked Washer
70 90228-060
Cog Belt
71 90228-061
Driven Pulley
72 90228-062 Screw M5x25
73 90228-063
Bearing Base
74 90228-064 Screw M6x25
75 90228-065 Screw M8X25
76 90228-066 Cog Belt Guard Cover
77 90228-067 Square Nut
78 90228-068
Driving Pulley
81 90228-071 Motor Assembly
82 90228-072 Power Cord
83 90228-077
Switch Protect Cover
84 90228-073
Dust Collection Port
85 90228-075
Belt Frame Support
86 90228-076
Belt Paper 80#
87 90228-079
Flat Washer 8
88 90228-080 Screw M8x16
89 6502-089 Tension Rod
90 6502-090 Pin Roll 5x8
91 90228-018 Screw ST4.2x20
92 90228-078 ScrewST2.9x8
94 90228-012 Screw M5x25
95 90228-040
Screw M5x20
96 6502-096 Ground Connection Lug
Item # Stock # Description
1 90228-001 Screw M4x6
2 90228-012 Screw M4x8
3 90228-003
Base Cover
4 90228-004 Screw ST4.2x10
5 90228-015 Lock Washer 4
6 90228-006 Disc Cover
7 90228-007 Disc Paper 80#
8 90228-008 Screw M6x16
9 90228-009 Lock Washer 5
10 90228-010
Disc
11 90228-011
Sanding Disc Guard
12 90228-012 Screw M5x8
13 90228-014 Flat washer 5
14 90228-026 Flat washer 5
15 90228-015 Lock Washer 5
16 6502-016 Pin Roll 5x10
17 90228-017
Base
18 6502-018 Cord Clip
19 90228-019
Wire Connection Box Cover
20 90228-020 Screw ST2.9x30
21 90228-021
Relay
22 90228-022
Wire Connection Box
23 6502-023 Glass Tube
24 90228-024
Power Switch
25 90228-023 Screw M4x10
26 90228-026 Spring Washer 6
27 90228-027 Hex Nut M5
28 90228-028
Capacitor
29 90228-029
Capacitor Support
30 90228-023 Screw M5x12
31 90228-031 Bolt M6x12
32 90228-032 Washer 6
33 90228-033
Work Table Support Angle Plate
34 90228-034
Miter Gauge Knob
35 90228-035
Work Table
36 6502-036 Miter Gauge Bar
37 6502-037 Point of Miter Gauge
38 6502-038 Miter Gauge of Work Table
39 6502-039 Cotter
40 90228-037
Tension Spring
41 90228-038
Bushing
42 90228-039
Belt Tension Support
43 6502-043 Tetaining Ring
44 6502-044 Bearing
45 6502-045 Idler Drum
46 6502-046 Idler Shaft
