Wen 6515 User Manual

2
TABLE OF CONTENTS
Specifications .................................................................................. 2
Introduction .................................................................................... 3
General Safety Rules ....................................................................... 4
Specific Safety Rules for the Belt/Disc Sander ................................. 6
Electrical Information ...................................................................... 8
Know Your Belt/Disc Sander ............................................................ 9
Assembly & Adjustments .............................................................. 10
Operation ...................................................................................... 15
Maintenance .................................................................................. 16
Troubleshooting Guide .................................................................. 18
Exploded View & Parts List ........................................................... 19
Warranty Statement ....................................................................... 21
Replacement sanding belts and sanding discs can be purchased from wenproducts.com by searching the
following model nubmers. For 400-grit, 240-grit, 180-grit, or 120-grit sanding belts search model num-
bers 6515SP400, 6515SP240, 6515SP180, or 6515SP120 respectively. For 120-grit, 240-grit, or 80-grit
sanding discs search model numbers 5SD120, 5SD240, or 5SD80 respectively.
SPECIFICATIONS
Model Numbers 6515, 6515T
Motor 120V, 60Hz, 2.3A
Disc Speed 3450 RPM (no load)
Disc Diameter 5 inches
Belt Speed 3160 FPM (no load)
Belt Size 1 x 30 inches
Belt/Disc Dust Port Size 1.7 inches (outer), 1.5 inches (inner)
Dust Port Adapter Size 2.25 inches (outer), 2 inches (inner)
Included Sanding Disc 80 Grit
Included Sanding Belt 120 Grit
Weight 16 lbs
Product Dimensions 14 x 11.5 x 15.5 inches
