KNOW YOUR BELT/DISC SANDER
TOOL PURPOSE
Belt and disc sanders shape and finish wood and a variety of other materials. The belt and disc rotates to
help smooth workpiece surfaces quickly and evenly. Refer to the diagram below to become familiarized with
the parts and controls of your belt/disc sander.
CLEANING THE WORK TABLE SURFACE
Your sander's work table comes protected with a layer of anti-rust coating. Clean the rust-protected surfaces
using a soft cloth, moistened with kerosene. Do not use gasoline, or cellulose-based solvents such as paint
thinner or lacquer thinner, as these will damage the painted surfaces.
After cleaning, apply a light coat of good-quality paste wax to the table to prevent rust. Wipe all parts thor-
oughly with a clean, dry cloth.
Sanding Belt
Upper Guard Knob
Belt Table
Adjusting Shaft Guard
Power Switch
Belt Tracking
Adjustment Knob
Sanding Disc
Disc Table
Miter Gauge
Locking Lever
Table Bevel Scale
Locking Knob
Disc Dust Port
Upper Guard
