EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 6530-013 Front Shoe 1
2 6530-014 Adjust Spring 1
3 6530-015 Adjust Support 1
4 6530-008 Regulative Shaft 1
5 6530-012 Front Shoe Ball Spring 1
6 6530-010 Ball Ø3.5 1
7 6530-009B Graduation Ring 1
8 6530-007 Adjust Knob 1
9 6530-004 Screw ST4x16 13
10 6530-006B Knob Cover 1
11 6530-065B Lock Knob 2
12 6530-062 Depth Scale 1
13 6530-057B Extraction Guide Knob 1
14 6530-011 Ball Ø4 1
15 6530-055
Extraction Guide
Ball Spring
1
16 6530-056 Spring Seat 1
17 6530-059 Fixation Frame 1
18 6530-060 Bolt M6x12 1
19 6530-028 Washer 6 2
20 6530-058 Thumb Nut M6 1
21 6530-040 Cable Clamp 1
22 6530-061 Rabbeting Depth Stop 1
23 6530-053 Cable Bushing 1
24 6530-044B ON/OFF Switch 1
26 6530-038 Carbon Brush 2
27 6530-039 Brush Lining 2
28 6530-036 Washer 4 2
29 6530-035 Screw ST4x55 2
30 6530-034 Rotor 1
31 6530-033 Rotor Ball Bearing 2
32 6530-066 Power Cord 1
No. Part No. Description Qty.
33 6530-067 Connecting Hose 1
34 6530-068 Dust Bag 1
35 6530-064B Wrench Box 1
36 6530-063 Blade Wrench 40Mm 1
37 6530-032 Driving Wheel 1
38 6530-029 Nut M6 1
39 6530-016 Belt 1
40 6530-030 Left Housing 1
41 6530-041B Logo Sticker 1
42 6530-042 Screw ST4x13 13
43 6530-017 Belt Cover 1
44 6530-051 Rear Shoe 1
45 6530-046B Tool Park Rest 1
46 6530-052 Panel Strip 2
47 6530-002 Motor Cover 1
48 6530-048 Adjusting Plate Knob 1
49 6530-054 Adjusting Plate 1
50 6530-001 Nameplate 1
51 6530-005 Right Housing 1
52 6530-070 Screw ST4x25 1
53 6530-018 Lock Sleeve 1
54 6530-019 Torsional Spring 1
55 6530-037 Stator 1
56 6530-020 Blade Guard 1
57 6530-021 Tool Carrier 1
58 6530-022 Blade Drum Bearing 1 1
59 6530-031 Air Deector 1
60 6530-023 Cutter Drum 1
61 6530-024 Blade Drum Bearing 2 1
62 6530-026 Big Washer 1
63 6530-027 Belt Pulley 1
64 6530B Planer Blade (Not Pictured) 2
17
NOTE: Parts and accessories that wear down over the course of normal use (e.g. blades, carbon brushes, etc.)
are not covered by the two-year warranty. Replacement parts can be purchased from wenproducts.com, or by call-
ing our customer service at (800) 232-1195, M-F 8-5 CST.
