No. Part No. Description Qty.
1 6530-013 Front Shoe 1
2 6530-014 Front Shoe Spring 1
3 6530-015 Front Shoe Spring Bracket 1
4 6530-008 Depth Regulating Shaft 1
5 6530-012 Ball Spring 1
6 6530-010 Ball, 3.5mm 1
7 6530-009B Depth Gauge Ring 1
8 6530-007 Depth Knob 1
9 6530-004 Screw, ST4x16 13
10 6530-006B Knob Cover 1
11 6530-065B Lock Knob 2
12 6530-062 Rabbeting Depth Stop 1
13 6530-057B Dust Extractor Guide Knob 1
14 6530-011 Ball, 4mm 1
15 6530-055 Extractor Guide Spring 1
16 6530-056 Spring Seat 1
17 6530-059 Fence Bracket 1
18 6530-060 Bolt, M6x12 1
19 6530-028 Washer, 6mm 1
20 6530-058 Wing Nut, M6 1
21 6530-040 Power Cord Clamp 1
22 6530-061 Parallel Guide Fence 1
23 6530-053 Power Cord Strain Relief 1
24 6530-044B Power Switch 1
26 6530-038 Carbon Brush 2
27 6530-039 Brush Holder 2
28 6530-036 Washer, 4mm 2
29 6530-035 Screw, ST4x55 2
30 6530-034 Rotor 1
31 6530-033 Ball Bearing 2
32 6530-066 Power Cord 1
No. Part No. Description Qty.
33 6530-067 Dust Bag Frame 1
34 6530-068 Dust Bag 1
35 6530-064B Wrench Handle 1
36 6530-063 Wrench, 8mm 1
37 6530-032 Driving Pulley 1
38 6530-029 Nut, M6 1
39 6530-016 Belt 1
40 6530-030 Left Housing 1
41 6530-041B Logo Label 1
42 6530-042 Screw, ST4x13 13
43 6530-017 Belt Cover 1
44 6530-051 Rear Shoe 1
45 6530-046B Kickstand 1
46 6530-052 Rear Shoe Bracket 2
47 6530-002 Motor Cover 1
48 6530-048 Extractor Base Plate 1
49 6530-054 Extractor Deflector Plate 1
50 6530-001 Main Label 1
51 6530-005 Right Housing 1
52 6530-070 Screw, ST4x25 1
53 6530-018 Locking Sleeve 1
54 6530-019 Torsional Spring 1
55 6530-037 Stator 1
56 6530-020 Guard 1
57 6530-021 Cutterhead Mount 1
58 6530-022 Cutterhead Bearing 1 1
59 6530-031 Motor Baffle 1
60 6530-023 Cutterhead 1
61 6530-024 Cutterhead Bearing 2 1
62 6530-026 Big Washer 1
63 6530-027 Belt Pulley 1
N.P. 6530B Planer Blade 2
NOTE: Parts and accessories that wear down over the course of normal use (e.g. blades, carbon brushes, etc.) are
not covered by the two-year warranty. Replacement parts can be purchased from wenproducts.com, or by calling
our customer service at 1 (800) 232-1195, M-F 8-5 CST.
EXPLODED VIEW & PARTS LIST
18
