KNOW YOUR HANDHELD PLANER
TOOL PURPOSE
The power to trim doors, flatten boards, and much more is in the palm of your hand with your WEN Handheld Planer.
Refer to the following diagrams to become familiarized with all the parts and controls of your handheld planer. The
components will be referred to later in the manual for assembly and operation instructions.
Depth Adjustment Knob
Rabbeting Lock Knob
Depth Adjustment Gauge
Adjustable Front Shoe
Chip Extraction Guide Switch
Handle
Chip Extraction Port
Trigger Switch
ON / OFF Switch
Blade Wrench
Fixed Rear Shoe
Chip Extraction Port
Drive Belt Cover
Parallel Guide Lock Knob
Dust Bag Rabbeting Depth Stop Parallel Guide Fence
9
