Wen 6550

TABLE OF CONTENTS
Technical Data
2
3
4
5
7
7
10
14
16
18
22
General Safety Rules
Specific Safety Rules For Planer
Electrical Information
Know Your Planer
Assembly and Adjustments
Operation
Exploded View and Parts List
Warranty
TECHNICAL DATA
Model Number:
Motor:
Cutterhead Speed:
Cuts Per Minute:
Feed rate:
Maximum Depth of Cut:
Table Size:
Extension Table Size:
Base Size:
Workpiece Width (max.):
Workpiece Thickness (max.):
Workpiece Thickness (min.):
Minimum Depth Stop Height:
Weight:
6550
120V, 60 Hz, 15A, 2.41 HP
8500 RPM
17,000 cuts per minute
26 FPM
3/32˝ (for workpieces under 6˝ wide)
1/32 (for workpieces over 6˝ wide)
12-1/2 x 9-3/8˝
12-1/2 x 6-3/4˝
21 x 12-1/2˝
12-1/2˝
6˝
1/4” (1/2” recommended min.)
5/32” (not recommended)
73 lbs
2
Maintenance
Troubleshooting
