Wen 6550 User Manual

No. Part No. Description Qty.
1 6550-101 Screw 4
1A 6550-101A Flat Washer, 6mm 4
2 6550-102 Left Cap 1
3 6550-103 Cotter Pin 2
4 6550-104 Roller 1
5 6550-105 Handle Assembly 1
6 6550-106 Right Cap 1
7 6550-107 Grip 2
8 6550-108 Elevating Nut (RH) 2
9 6550-109 Left Side Cover 1
10 6550-110 Bolt 9
11 6550-111 Spacer 1
12 6550-112 Elevating Screw (LH) 1
13 6550-113 Column 4
14 6550-114 Screw 3
15 6550-115 Guide 2
16 6550-116 Table 1
17 6550-117 Elevating Screw (RH) 1
18 6550-118
Extension Table Assem-
bly
2
19 6550-119 Table Support 4
No. Part No. Description Qty.
20 6550-120 Base 1
21 6550-121 Plate 3
22 6550-122 Set Screw 3
23 6550-123 Nut 4
24 6550-124 Adjustment Screw 4
25 6550-125 Lock Washer, 10mm 4
26 6550-126 Bolt 4
27 6550-127 Screw With Washer 8
28 6550-128 Screw 4
29 6550-129 Bushing 4
30 6550-130 Wavy Washer 4
31 6550-131 Shaft 1
32 6550-132 Support 2
33 6550-133 Retaining Ring 2
34 6550-134 Bevel Gear 4
35 6550-135
Elevation Screw Bearing
Assembly
2
36 6550-136 Right Side Cover 1
37 6550-137 Wrench 1
38 6550-138 Magnet 2
39 6550-139 Elevating Nut (LH) 2
EXPLODED VIEW & PARTS LIST
19

Wen 6550 Specifications

General

Brand	Wen
Model	6550
Category	Planer
Language	English
