KNOW YOUR WOOD JOINTER
9
UNPACKING
With the help of a friend or trustworthy foe, carefully remove the jointer from the packaging. Make sure
to take out all contents and accessories. Do not discard the packaging until the jointer is completely
assembled.
Before using the jointer, you must assemble the unit using the instructions in this section. Check your
packing list against the diagram below. If any part is damaged or missing, please contact our customer
service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com.
PACKING LIST
A. Jointer
B. Fence
C. Fence Bracket Assembly
D. Fence Sliding Base
E. Spring
F. 4 mm Hex Wrench
G. Lock Handle
H. Flat Washer
I. Square Nut
J. Filter Bag
K. Dust Chute
L. Push Block
M. Push Stick
A B C
D
E F
H
G
IJ
K L
M
Outfeed Table
Dust Port
Blade Guard
Power Switch
Infeed Adjustment Knob
Infeed Table
Fence
WARNING: Do not plug in or turn on the tool until it is fully assembled according to the
instructions. Failure to follow the safety instructions may result in serious personal injury.
