EXPLODED VIEW & PARTS LIST
No. Model No. Description Qty
1 65812-001 Motor Assembly 1
2 65812-002 Base 1
3 65812-003 Dust Cover 1
4 65812-004 Work Table 1
5 65812-005 Hose Assembly 1
6 65812-006 Scale Plate 2
7 65812-007 Locating Pin 2
8 65812-008 Bevel Locking Knob 2
9 65812-009 Disc Guard 1
10 65812-010 Miter Gauge Knob 1
11 65812-011 Miter Gauge 1
12 65812-012 Screw M5x8 1
13 65812-013 Miter Gauge Pointer 1
14 65812-014 Miter Rod 1
15 65812-015 Hex Bolt M6x10 6
16 65812-016 Rubber Feet 4
17 65812-017 Big Flat Washer D6 7
18 65812-018 Screw M6x20 6
19 65812-019 Rubber Washer 2
20 65812-020 Screw M5x8 2
21 65812-021 Hex Bolt M8x25 4
22 65812-022 Bevel Scale Plate Pointer 1
23 65812-023 Screw M4x8 1
24 65812-024 Screw M6x20 1
25 65812-025 Disc Plate 1
26 65812SD60 60-Grit Sanding Disc 1
27 65812-027 Sander Washer 1
17
