ASSEMBLY & ADJUSTMENTS
WARNING! Only anchor the air filtration system to build-
ing structures capable of holding at least 100 lbs. Do not
mount the air filtration system to non-structural surfaces such
as drywall or false ceiling grids. The unit must be situated at
least 7 feet above the floor (for best airflow performance, as
well as to help you avoid hitting your head) and at least 3 feet
(1 m) away from any heating, cooling, or air circulation vents.
CEILING MOUNTING
1. Install the wood screw hooks (Fig. 5 - 1) into the building sup-
port structure.
NOTE: Wood screw hooks and chains used for ceiling mounting
are not included. Make sure to use chain and hooks that are prop-
erly rated for hanging this unit.
2. Place a chain (Fig. 5 - 2) on each wood screw hook.
3. Attach the chain onto the mounting hangers (Fig. 5 - 3). The four mounting brackets can also be used for mount-
ing the unit onto the ceiling or wall.
4. Make sure the unit is horizontally level, and is at least 7 feet above the floor (this maximizes airflow and helps
prevent you from hitting your head). If it is not, remove the unit and adjust the length of the chain as needed. Then
remount the unit.
Fig. 5
1
2
3
10
