EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 3415-001
Phillips Head Screw
M6x16
12
2 3415-002 Lock Washer, 6mm 14
3 3415-003
Phillips Head Screw
M4x2
2
4 3415-004 Fan Housing 1
5 3415-005
Cap Screw M6x20
(LH)
1
6 3415-006 Flange Disk 1
7 3415-007 Hex Bolt, M8x8 1
8 3415-008 Key, 4x4x20 1
9 AF1270-009 Fan 1
10 3415-010 Hex Bolt, M6x10 8
11 3415-011 Flat Washer, 6mm 8
12 3415-012 Flange Bracket 4
13 3415-013 Hex Bolt, M6x30 4
14 3415-014 Flat Washer, 6mm 5
15 3415-015 Sleeve 4
16 3415-016 Spacer 4
17 3415-017 Flange 1
18 3415-018 Lock Nut M5-0.8 4
19 3416-019 Motor 1
20 3416-020 Capacitor, 12 mFD 1
21 3415-021 Filter Retaining Latch 2
22 3415AF1 Inner Filter, 1-micron 1
23 3415-023
Foam Seal (incl. in
Inner Filter)
1
24 3415AF5 Outer Filter, 5-micron 1
25 3415-025 Handle 2
26 3415-026 Rubber Foot 4
27 3415-027 Flat Washer, 6mm 6
28 3415-028 Rivet Nut M10x21 4
No. Part No. Description Qty.
29 3415-029 Mount And Bolt Bag 1
30 3415-030 Housing 1
31 3415-031 Eye Bolt M10x20 4
33 3415-033 PCB Wiring Harness 1
34 3415-034
Phillips Head Screw
M4x16
3
35 3415-035 Lock Washer, 4mm 5
36 3415-036 Flat Washer, 4mm 5
37 3415-037 Hex Nut, M4 5
38 3415-038 Toothed Washer, 4mm 5
39 3415-039
Phillips Head Screw
(Special)
3
40 3415-040 Spacer (Special) 1
41 3415-041
Phillips Head Screw,
M3x6
3
42 3416-042 PCB 1
43 3416-043 Label (Controls) 1
44 3415-044
Phillips Head Screw
M4x10
4
45 3415-045 Control Panel 1
46 3415-046 Strain Relief 1
47 3415-047 Power Cord 1
50
3416-050
Remote Control
Assembly
151
52
53 3415-053 Flat Washer, 4mm 2
54 3415-054 Lock Washer, 4mm 2
55 3415-055 Motor Grating 1
56 3416-056 Fuse Holder 1
57 3416-057
Fuse, F8AL250V,
6x30mm
1
58 3415-058 Remote Battery 2
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.
15
