Wen DF472X

EXPLODED VIEW & PARTS LIST
ENGINE
No. Part No. Description Qty.
1
DF475-101 Crankcase 1
2 DF475-102 Ball Bearing 2
3 DF475-103 Oil Seal 2
4 DF475-104 Governor Assembly 1
5 DF475-105 Governor Arm Shaft 1
6 DF475-106
Governor Arm Shaft
Washer
1
7 DF475-107 Lock Pin 1
8 DF475-108 Drain Plug Bolt 2
9 DF475-109 Drain Plug Washer 2
10 DF475-110
Oil Level Switch
Assembly
1
11 DF475-111 Bolt M6x16 2
12 DF475-112
Crankcase Cover
Dowel Pin, Ø8x12
2
13 DF475-113 Piston 1
14 DF475-114
Piston Scraper Ring
Set
1
15 DF475-115
Connecting Rod
Assembly
1
16 DF475-116 Piston Pin 1
17 DF475-117 Piston Clip 2
18 DF475-118
Crankcase Cover
Assembly
1
19 DF475-119 Cylinder Head 1
20 DF475-120 In-Valve 1
21 DF475-121 Valve Exhaust 1
22 DF475-122
Intake Valve
Returner
1
23 DF475-123 Valve Spring 2
24 DF475-124 In-Valve Spring Seat 1
25 DF475-125 Ex-Valve Spring Seat 1
No. Part No. Description Qty.
26 DF475-126
Push Rod Guide
Plate
1
27 DF475-127 Rocker Assembly 2
28 DF475-128 Rotator 1
29 DF475-129 Carburetor Stud Bolt 2
30 DF475-130 Stud Bolt 2
31 DF472-131
Carburetor
Assembly
1
32 DF472-132 Fuel Line 1
33 DF475-133 CLIP,FUEL LINE Ф7.5 1
34 DF475-134 GOVERNOR ARM 1
35 DF472-135 LPG Line 1
36 DF475-136 Nut M6 2
37 DF475-137
Crankshaft
Assembly
1
38 DF475-138 Valve Lifter 2
39 DF475-139 Casecover Packing 1
40 DF475-140 Camshaft Assembly 1
41 DF475-141 Dowel Pin 2
42 DF475-142 Bolt M8x30 6
43 DF475-143
Cylinder Head
Gasket
1
44 DF475-144 Bolt M8x60 4
45 DF475-145
Spark Plug, Torch
F7TC (NGK BP7ES)
1
46 DF475-146 Push Rod 2
47 DF475-147 Shroud 1
48 DF475-148 Bolt M6x12 12
49 DF475-149 Headcover Packing 1
50 DF475-150 Cylinder Head Cover 1
51 DF472-151 Shroud 1
52 DF472-152 Bolt, M6x20 1
53 DF475-153 Recoil Starter Fan 1
