EXPLODED VIEW & PARTS LIST
ENGINE
No. Part No. Description Qty.
54 DF475-154 Starter Pulley 1
55 DF475-155 Nut M14 1
56 DF475-156
Ignition Coil
Assembly
1
57 DF475-157 Bolt M6X25 2
58 DF475-158 Intake Packing 1
59 DF475-159 Carburetor Insulator 1
60 DF475-160 Carburetor Packing 1
61 DF475-161 Carburetor Spacer 1
62 DF475-162 Governor Rod 1
63 DF475-163
Throttle Return
Spring
1
No. Part No. Description Qty.
64 DF472X-164
Recoil Starter
Assembly
1
65 DF475-165
Upper Shroud
Assembly
1
66
DF472-
166ASM
Air Filter Assembly 1
67 DF475-167 Breather Tube 1
68 DF472-168 Clip 1
69 DF475-169 Governor Spring 1
70 DF475-170 Clip 1
71 DF475-171 Dipstick 1
72 DF475-172 Bolt M6X30 2
73 DF472-173 Flywheel Assembly 1
39
