Wen DF475X

EXPLODED VIEW & PARTS LIST
GENERATOR
No. Part No. Description Qty.
1 DF475X-001 Alternator Assembly
1
1.1 DF475-001.1
Carbon Brush
Assembly
1
2 DF475-002 Motor Stand
1
3 DF475-003 Switch Dial Assembly
1
4 DF475-004
Hexagon Pattern Pan
Head Screws M6x12
1
5 DF475-005 Nut M8
2
6 DF475-006 Wire Harness Clip
2
7 DF475X-007 Frame
1
8 DF475-008 Isolator A
2
9 DF475-009 Isolator B
2
10 DF475-010 Fuel Filter
1
11 DF475X-011 Fuel Tank Assembly
1
12 DF475-012 Fuel Cock
1
13 DF475X-013 Regulator Assembly
1
14 DF475X-014 Regulator
1
15 DF475-015 Bolt M6x55
1
16 DF475-016 Flat Washer
2
17 DF475-017 Bolt M8-1x220
1
18 DF475-018
Rotor Bolt Gasket
Ø8.5x24x3
1
19 DF475-019 Handle Assembly
1
20 DF475-020 Bolt M6x175
4
21 DF475-021 Bolt M6x12
13
22 DF475-022 Nut M5
3
23 DF475-023 Air Cleaner Bracket
1
24 DF475-024 Exhaust Packing
1
25 DF475-025 Cotter Pin
2
26 DF475-026 Muffler Comp
1
27 DF475-027 Spring Washer Ø8
2
28 DF475X-028 Vibration Isolation Pad
1
No. Part No. Description Qty.
29 DF475X-029ASM
Control Panel
Assembly
1
29.1 DF475-029.1 Ignition Switch
1
N.P. P55340 Starter Key (set of 2)
1
29.2 DF475-029.2 DC Receptacle, 12V
1
29.3 DF475-029.3 DC Breaker, 8A
1
29.4 DF475X-029.4
NEMA 5-20R 120V
20A GFCI Duplex
Outlet
1
29.5 DF475-029.5 AC Breaker, 20A
1
29.6 DF475-029.9 Grounding Lug
1
29.7 DF475-029.6
Voltage Selector
Switch
1
29.8 DF475-029.7 AC Breaker, 16A
2
29.9 DF475-029.8
NEMA L14-30R
125V/250V 30A
Receptacle
1
29.10 DF475-029.10 Rectifier
1
29.11 DF1100-029.11 Charger
29.12 DF475X-029.12 CO Sensor LED
30 DF475-030 Handle Clip
1
31 DF475-031 Bolt M8x35
2
32 DF475-032 Bolt M6x40
4
33 DF475-033 Voltage Regulator
1
34 DF475-034 Bolt M5x16
1
35 DF475-035 Bolt M5x12
7
36 DF475X-036
CO Sensor Engine
Controller
1
37 DF475X-037 Bolt M6x25
4
38 DF475-038 End Cover
1
39 DF475-039 Positive Lead
1
40 DF475-040 Negative Lead
1
41 DF475-041 Battery 12V 7Ah
1
42 DF475-042 Wheel
2
38
