Wen DF475X

EXPLODED VIEW & PARTS LIST
GENERATOR
No. Part No. Description Qty.
43 DF475-043 Frame Support
2
44 DF475-044 Vibration Isolation Pad
2
45 DF475-045 Nut M6
9
46 DF475-046 Bolt M8X16
2
47 DF475-047 Clip Ø12
2
48 DF475-048 Wheel Axle
2
49 DF475-049 Handle Connector
1
50 DF475-050 Muffler Bracket
1
51 DF475X-051 Battery Bracket
1
52 DF475X-052 Battery Bolt
1
53 DF475-077 Dustproof Sheet
1
54 DF475X-054 Low Pressure Hose
1
55 DF475X-055 Fuel Line 1
1
56 DF475X-056 Fuel Line 2
1
57 DF475-057
Connecting Pipe (Gas
Tank)
1
58 DF475-058
Manual Choke
Assembly
1
59 DF475-059 Handle Bolt
1
60 DF475-060 Fuel Line Clip Ø7.5
1
61 DF475X-061 Fuel Line Clip Ø9.5
5
No. Part No. Description Qty.
62 DF475-062 Frame Wire
1
63 DF475-063 Fuel Line Clip Ø10
1
64 DF475-064 Nut M8
12
65 DF475-065 Tooth Type Gasket Ø6
1
66 DF475X-066 CO Sensor Module
1
67 DF475-067 Handle Rubber
1
68 DF475X-068ASM Engine Assembly
1
69 DF475-069 Grounding Wire
1
70 DF475X-070 Fuel Selector Switch
1
71 DF475X-071 Fuel Line Clip Ø11.5
1
72 DF475-072 Paper Washer
5
73 DF475X-073
Fuel Tank Cap
Assembly
1
74 DF475-074 LPG Regulator Cover
1
75 DF475X-075 Carbon Tank Assembly
1
76 DF475-076 Connecting Pipe
1
77 DF475X-077 Fuel Line Clip Ø12
1
78 DF475X-078
Phillips Head Screw,
M4x28
2
N.P. DF475-078 Fuel Gauge
1
N.P. DF475-079 Fuel Tank Filter
1
