To connect your generator to an LPG cylinder:
1. Take off the safety caps from the cylinder valve, generator-mounted
regulator, and regulator connecting hose ends.
2. With the LPG tank closed, attach the first-stage regulator to the valve.
Turn the regulator’s plastic coupling right (clockwise) to tighten the as-
sembly onto the LPG tank (Fig. 6).
3. Connect the other end of the hose to the generator’s onboard regula-
tor (Fig. 7 - 1) with a 3/4 in. (19mm) wrench (not supplied).
4. Turn the LPG tank valve ON and check for leaks by spraying soapy
water to check the connections. If bubbles appear, become larger in size,
or increase in number, a leak exists. This must be corrected before using
the generator. Contact your local Independent Authorized Service Dealer
(IASD) for assistance.
NOTE: You can use Teflon (or other tape) to help seal the connection
between the regulator hose and the generator.
CAUTION! Always position the LPG cylinder so the connection
between the valve and regulator won’t cause sharp bends or kinks in
hose.
WARNING! Risk of burns. Contact with liquid contents of cylinder
will cause freeze burns to the skin. If liquid contents contacts skin or
eyes, seek immediate medical attention.
WARNING! When transporting and storing, keep cylinder
secured in an upright position with cylinder valve turned off. Keep
cylinders ventilated and away from heat when in a vehicle.
GENERATOR PREPARATION
1
Fig. 6
Fig. 7
17
