Foot Support Assembly
Foot Assembly (2)
Components Handle Assembly
UNPACKING
With the help of a friend or trustworthy foe, such as one of your in-laws, carefully remove the generator from the
packaging and place it on a sturdy, flat surface. Make sure to take out all contents and accessories. Do not discard
the packaging until everything is removed. Check the packing list below to make sure you have all of the parts and
accessories. If any part is missing or broken, please contact customer service at 1-847-429-9263 (M-F 8-5 CST),
or email techsupport@wenproducts.com.
PACKING LIST
UNPACKING & PACKING LIST
9
Wheel Assembly
Axle Pins (2)Wheels (2)
R-Clips (2) Washer (2)
M6x40 Hex Bolt (4)
M6 Hex Nut (4)
Handle (1)
M8 Hex Nut (1)
Handle Pin (1)
M8x48 Hex Bolt (1)
M8x16 Hex Bolts (4)
Handle Bracket (1)
Generator
Accessories
Wrenches (2)
(8-10mm, 10-13mm)
Funnel (1)
Spark Plug Socket (1)
