EXPLODED VIEW & PARTS LIST
JT833H
No. Part No. Description Qty.
1_S
JT833H-
001ASM
Table Assy. 2
2 JT833H-002 Right Cover 1
3 JT630H-003 Outfeed Support 1
4 JT630H-004 Set Screw M6x8 8
5 JT833H-005 Left Cover 1
6 JT630H-006 Screw M6x12 16
7 JT630H-007 Screw 4
8 JT833H-008 Dust Chute 1
9 JT833H-009 Cutter Head Foam Seal 1
10 JT833H-010 Front Foam Seal 1
12 JT630H-012 Front Frame 1
13 JT833H-013 Dust Port 1
14_S
JT630H-
014ASM
Bearing Retainer Assy. 1
17 JT630H-017 C-Ring 1
20 JT630H-020 Pointer 1
21 JT630H-021 Gear 1
23 JT630H-023 Lock Knob M8 2
24 JT630H-024 M8 Flat Washer 3
25 JT630H-025 Foot 4
26 JT630H-026 Retaining Ring 1
27 JT630H-027 Screw M5-0.8x8 2
27a
JT630H-
027A
Lock Washer 2
27b
JT630H-
027B
Hex Nut M5 10
28 JT630H-028 Screw M5-0.8x25 4
28a
JT630H-
028A
Lock Nut 4
29 JT630H-029 Switch Box 1
30_S
JT833H-
030ASM
Spiral Cutterhead
Assy.
1
32 BP510H HSS Blade 16
33 JT630H-163 Star Head Cap Screw 16
34 JT630H-034 Rear Frame 1
35 JT630H-035 Hole Plug 4
36_S
JT630H-
036ASM
Bearing Retainer Assy. 1
No. Part No. Description Qty.
37 JT630H-166 Star Wrench 1
39 JT630H-039 Cutterhead Pulley 1
40 JT630H-040 Belt 1
41 JT630H-041 Belt Guard 1
43
JT630H-
043A
Screw M12-1.25x15 8
44 JT833H-044 Dust Adaptor 1
45 JT833H-045 Back Foam Seal 1
46 JT630H-046 M6 Star Screw 8
48 JT630H-048 Flange Nut 16
49 JT833H-049 Support Rod 8
50 JT630H-050 Cord Clamp 1
51_S
JT833H-
051ASM
Infeed Support Assy. 1
70 JT630H-070 Jointer Push Block 2
71 JT630H-071 2.5 mm Hex Wrench 1
72 JT630H-072 4 mm Hex Wrench 1
102_S
JT630H-
101ASM
Blade Guard Assy. 1
110 JT833H-110 Logo Label 1
111 JT833H-111 Specs Label 1
112 JT833H-112 Warning Label 1
115 JT833H-115 Blade Guard Label 1
117 JT630H-022 Depth Label 1
125 JT630H-125 Fence 1
128 JT630H-128 Bevel Bracket 1
129 JT630H-129 Square Nut 2
130 JT630H-130 Rectangle Nut 2
131 JT630H-131 Set Screw M5-0.8x8 2
132 JT630H-132 Intermediate Bracket 1
133S
JT630H-
133ASM
Fence Sliding Handle 1
135S
JT630H-
135ASM
Fence Bevel Handle 1
136 JT630H-136 Fence Slide Bracket 1
137 JT630H-137 Fence Bracket 1
138 JT630H-138 Flat Washer 3
139 JT630H-139 Screw M6x16 6
23
