Wen PL1252 User Manual

No. Part No. Description Qty.
103
Cutterhead Cover
Warning Label
1
111 Logo Label 1
112 Table Support 2
126 Scale 1
132
Pan Head Screw with
Washer, M4x8
4
133_S
PL1252-
133ASM
Cutterhead Cover 1
135
Extension Table
Support Bracket
4
136 Spring Washer 4
137 Table Bushing 4
138
Pan Head Screw,
M6x16
4
139 Spring, Left Rear 1
140
Pan Head Screw,
M4x6
8
141 Nut, M6 5
142 Bolt, M6x20 5
159 PL1252-159 Switch 1
160 PL1252-160 Switch Key 1
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
178 PL1326-190 Carbon Brush Cover 2
179 PL1326-189 Carbon Brush 2
180 Carbon Brush Holder 2
185 PL1326-170B Breaker, 15A 1
190_S
Return Roller
Assembly
2
225 Cutterhead Spring 4
226 Chain 1
227 PL1303-030
Blade Removal
Magnet
1
229_S Cutterhead Assembly 1
230 PL1252-230
Cutterhead Guard
Knob
2
232 Gib 2
233 Hook-and-Loop Strip 1
234 BP122K Blade 2
238 Table Wear Plate 1
239 Bearing Block 4
240
Bearing Block Bracket,
Left
2
241
Bearing Block Bracket,
Right
2
22
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.

Wen PL1252 Specifications

General

Brand	Wen
Model	PL1252
Category	Planer
Language	English
