EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1_S
PL1303-
001_S
Top Cover Assembly 1
2
Socket Head Cap
Scew, M6x8
12
K4 Elevation Nut 8
R6 Rollercase 1
7 PL1303-007 Left Cover 1
8 PL1303-008 Right Cover 1
9 PL1326-009 Knob 2
12
Self-Tapping Screw,
M3-1.0x16
2
13 Idler Sprocket 2
14 Idler Sprocket Shaft 2
15 Leadscrew 3
16 Elevation Leadscrew 1
17
Socket Head Cap
Screw, M5-0.8x20
1
18_S
PL1303-
018ASM
Elevation Handle As-
sembly
1
K19 Base 1
20 PL1326-020 Hex Wrench, 4mm 1
21 PL1326-021 Star Wrench, T25 1
R22 Belt Cover 1
23 Spacer 1
24 Set Screw, M5-0.8x5 1
25 PL1326-025 Depth Indicator 1
R26_S
PL1326-
0R26ASM
Depth Stop Assembly 1
R28 Bearing Retainer Plate 4
29 Washer 4
30
Blade Removal Mag-
net
1
31 Spring Cap 1
R32 Handwheel Bracket 1
33 Chain Sprocket 4
34 Spring 1
35 Depth Stop Knob 1
36 Depth Stop Cover 1
37
Socket Head Cap
Screw, M6-1x12
1
No. Part No. Description Qty.
38
Bearing Retainer
Washer
4
39_S
PL1326-
039ASM
Dust Chute Assembly 1
R40
Dust Chute Lower
Door
1
R41 Dust Chute Half-Seal 1
R42 PL1326-0R42 Dust Chute Adapter 1
43 Cutterhead Lock 1
44
Cutterhead Lock
Spacer
1
45
Socket Head Cap
Screw, M5-0.8x12
1
46
Phillips Screw, M4-
0.7x10
11
47 Screw, M5-0.8x8 3
48 Chip Deflector 1
49 Set Screw, M5-0.8x8 1
50 Screw, M5-0.8x10 1
51 Cord Clamp 1
54 Washer 1
55
Hex Socket Button
Screw, M8-1.25x20
1
66 PL1326-066 V-belt 1
69 6552-043 Blade 3
69A PL1303-069A Spring 6
70_S Cutterhead Assembly 1
71 PL1303-071
Star Screw, T25, M6-
1.0x14
21
71A PL1303-071A Gib 3
72 Hex Nut, M10-1.5 1
M73 Handwheel Rod 1
74 Hex Nut, M5-0.8 1
75
Handwheel Adjust-
ment Screw, M5-
0.8x14
1
76 Screw, M5-0.8x6 8
77
Phillips Button Screw,
M3-0.5x22
2
21
