No. Part No. Description Qty.
78
Hex Socket Button
Screw M5-0.8x12
10
81_S
PL1326-
081ASM
Depth-of-Cut Assem-
bly
1
87 Grounding Screw 2
88 Lock Washer 2
90 C-ring 3
91 Drive Chain Sprocket 4
92 Drive Chain 2
93 Spring, Left 2
94 Bearing Block 4
95 Outfeed Roller 1
96 Spring, Right 2
97
Bearing Block Retainer
Plate
4
98
Socket Head Cap
Screw
8
99 Infeed Roller 1
100 PL1326-100 Gearbox Cover 1
102_S
PL1326-
102ASM
Gearbox Assembly 1
113
Screw with Washer,
M5-0.8x35
4
115 Gearbox Spacer 1
116
Screw with Washer,
M5-0.8x10
8
117 Table Support 2
118 Table 1
119 PL1326-119 Extension Table 2
121 Washer 2
128 Scale 1
129 Spacer 4
133 Spring 1
134 Steel Ball 1
M135 Pivot Rod 1
136
Adjusting Screw,
M10-1.5
4
137 Hex Nut, M10-1.5 4
140 Hex Screw, M6-1x25 4
141 Hex Nut, M6-1 4
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
142 Ball Bearing 5
143 Washer 4
144
Socket Head Cap
Screw, M4-0.7x12
4
146 PL1326-146 Chain 1
147
Hex Socket Screw,
M5-0.8x25
2
148
Socket Head Cap
Screw, M5-0.8x16
2
153 Plug 1
155 Washer 4
163 Spring Washer 2
164 Flat Washer 4
170 PL1326-170B Breaker, 15A 1
172 PL1326-172 Switch Key 1
173 PL1326-173 Switch 1
188 Brush Holder 2
189 PL1326-189 Carbon Brush 2
190 PL1326-190 Carbon Brush Cover 2
191 Label, Logo 1
195 Label, Nameplate 1
198 PL1326-198 Cutterhead Side Guard 1
203 Label, Safety 1
205
Label, Blade Replace-
ment
1
600_S
PL1326-
600ASM
Motor Assembly 1
22
NOTE: Not all parts may be available for purchase. Parts
and accessories that wear down over the course of nor-
mal use are not covered under the warranty.
To Next Page
