EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1_S
PL1326-
001ASM
Top Cover Assembly 1
2
Socket Head Cap
Screw
12
K4 Elevation Nut 8
R6 Rollercase 1
7 PL1326-007 Left Cover 1
8 PL1326-008 Right Cover 1
9 PL1326-009 Knob 2
12
Self-Tapping Screw,
M3-1.0x16
2
13 Idler Sprocket 2
14 Idler Sprocket Shaft 2
15 Leadscrew 3
16 Elevation Leadscrew 1
17
Socket Head Cap
Screw, M5-0.8x20
1
18_S
PL1326-
018ASM
Elevation Handle As-
sembly
1
K19 Base 1
20 PL1326-020 Hex Wrench, 4mm 1
21 PL1326-021 Star Wrench, T25 1
R22 Belt Cover 1
23 Spacer 1
24 Set Screw 1
25 PL1326-025 Depth Indicator 1
R26_S
PL1326-
0R26ASM
Depth Stop Assembly 1
R28 Bearing Retainer Plate 4
29 Washer 4
31 Return Roller Seat 4
R32 Handwheel Bracket 1
33 Chain Sprocket 4
34_S
PL1326-
034ASM
Return Roller Assem-
bly
2
35 Depth Stop Knob 1
36 Depth Stop Cover 1
37
Socket Head Cap
Screw, M6-1x12
1
No. Part No. Description Qty.
38
Bearing Retainer
Washer
4
39_S
PL1326-
039ASM
Dust Chute Assembly 1
R40
Dust Chute Lower
Door
1
R41 Dust Chute Half-Seal 1
R42
PL1326-
0R42
Dust Chute Adapter 1
46
Phillips Screw, M4-
0.7x10
11
47 Screw, M5-0.8x8 3
48 Chip Deflector 1
49 Set Screw 1
50 Screw, M5-0.8x10 1
51 Cord Clamp 1
54 Washer 1
55
Hex Socket Button
Screw
1
66 PL1326-066 V-belt 1
69 BP510H Cutter Insert, HSS 26
70_S Cutterhead Assembly 1
71 PL1326-071
Star Screw, M5-
0.8x9.6
26
72 Hex Nut 1
M73 Handwheel Rod 1
74 Hex Nut 1
75
Handwheel Adjust-
ment Screw
1
76 Screw 8
77 Phillips Button Screw 2
78
Hex Socket Button
Screw
18
81_S
PL1326-
081ASM
Depth-of-Cut Assem-
bly
1
87 Grounding Screw 2
88 Lock Washer 2
90 C-ring 3
91 Drive Chain Sprocket 4
21
NOTE: Not all parts may be available for purchase.
