Wen PL1326 User Manual

No. Part No. Description Qty.
92 Drive Chain 2
93 Spring, Left 2
94 Bearing Block 4
95 Outfeed Roller 1
96 Spring, Right 2
97
Bearing Block Retainer
Plate
4
98
Socket Head Cap
Screw
8
99 Infeed Roller 1
100 PL1326-100 Gearbox Cover 1
102_S
PL1326-
102ASM
Gearbox Assembly 1
113 Screw with Washer 4
115 Gearbox Spacer 1
116 Screw with Washer 8
117 Table Support 2
118 Table 1
119 PL1326-119 Extension Table 2
121 Washer 2
128 Scale 1
129 Spacer 4
133 Spring 1
134 Steel Ball 1
M135 Pivot Rod 1
136 Adjusting Screw 4
137 Hex Nut 4
EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
140 Hex Screw 4
141 Hex Nut 4
142 Ball Bearing 5
143 Washer 4
144
Socket Head Cap
Screw
4
146 PL1326-146 Chain 1
147 Hex Socket Screw 2
148
Socket Head Cap
Screw
2
155 Washer 4
163 Spring Washer 2
170 PL1326-170 Breaker, 20A 1
172 PL1326-172 Switch Key 1
173 PL1326-173 Switch 1
188 Brush Holder 2
189 PL1326-189 Carbon Brush 2
190 PL1326-190 Carbon Brush Cover 2
191 Label, Logo 1
195 Label, Nameplate 1
198 PL1326-198 Cutterhead Side Guard 1
203 Label, Safety 1
205
Label, Insert Replace-
ment
1
206 Label, Insert Warning 1
600_S
PL1326-
600ASM
Motor Assembly 1
22
NOTE: Not all parts may be available for purchase.
