OPERATING INSTRUCTIONS
1
Wall Bumper
2
Lock Indicator
3
Rung
4
Support Ring
5
Lock Release
6
Stile Tube
7
Bottom Rung
8
Stabiliser Bar
(3.2m & 3.8m models only)
1
2
4
3
5
6
7
8
OPERATING AND USAGE INSTRUCTIONS
IMPORTANT – read all instructions carefully before attempting to
operate or use the ladder. The ladder should be inspected after
delivery and before every use to conrm condition and operation of all
parts.
OPEN
CLOSE
Figure 1
Figure 2
Figure 3 Figure 4
Figure 5
Figure 6
Do not open / extend the ladder from either a middle or the top
ladder section. The ladder sections may not fully lock which
may lead to injury.
