28
PART LIST—Model No. WCTL41305.1 R0905A
1 1 Motor Belt
2 1 Pulley/Flywheel/Fan
3 4 Motor Nut
4* 1 Motor/Pulley/
Flywheel/Fan
5 1 Incline Motor Bolt
6 1 Controller Wire
7 1 Incline Motor
8 1 Filter Wire
9 1 Left Upright
10 1 Right Upright
11 1 Console Plate
12 1 Frame
13 1 Fan Cover
14 2 Fan Screw
15 4 Incline Motor Nut
16 4 Belt Guide Screw
17 1 Upright Wire Harness
18 2 Hood Bracket
19 1 Front Hood Bracket
20 2 Warning Decal
21 1 Reed Switch
22 1 Reed Switch Clip
23 2 1-lb. Weight
24 1 Controller
25 1 Electronics Bracket
26 1 Reset/Off
Circuit Breaker
27 1 Power Cord
28 1 Power Cord Grommet
29 4 Washer
30* 1 Latch Assembly
31 1
Incline Frame
32 2 Frame Pivot Bolt
33 2 Frame Pivot Spacer
34
1
Tension Bushing
35 1 Front Roller Adj. Bolt
36 1 Foot Rail Cap (Right)
37
2
Motor Tension Nut/
Front Roller Nut
38 4 Motor Bolt
39 2 3/4” Screw
40
1
Foot Rail Cap (Left)
41 1 Left Foot Rail
42 1 Front Roller/Pulley
43 1 Magnet
44 4 Platform Screw
45 2 Isolator
46 2 Center Platform Screw
47 4 2 3/4” Bolt
48 2 3-lb. Weight
49 2 Belt Guide
50 1 Fan
51 1 Front Belly Pan
52 9 3/4 Tek Screw
53 2 Cable Tie Clamp
54 1 Latch Decal, French
55 1 Walking Belt
56 4 2 1/2” Bolt
57 1 Rear Roller
58 4 Hood Screw
59 2 Rear Foot
60 1 iFIT Jack
61 1 Ground Wire
62 12 Electronic Screw
63 1 Left Rear Endcap
64 1 Right Rear Endcap
65 2 Rear Roller Adj. Bolt
66 1 Drive Motor
67 1 Latch Decal, English
68 2 Foot Rail Cover
69 2 Small Star Washer
70 1 Ground Wire, Front
71 1 Walking Platform
72 5 8” Cable Tie
73 1 Incline Bolt
74 1
Motor Tension Bolt
75 1 Right Foot Rail
76 6 Belly Pan Screw
77
1
Latch Housing
78 1 Console
79 1 Stop Bracket
80
4
Rail Cap Screw
81 8 Star Washer
82 1 Base
83 2 Incline Frame Bolt
84
1
Motor Tension
Washer
85 10 Latch Screw
86 2 Wheel Bolt
87 2 4” Bolt
88 1 Console Crossbar
89 1 Static Decal
90 1 Key/Clip
91 1 Incline Motor Belly Pan
92 3 Roller Adj. Washer
93 4 Nut
94 1 Motor Hood
95 2 Wheel
96 1 Incline Motor Shield
97 4 Base Pad
98 1 iFIT Wire
99 1 Upright Grommet
100 1 Allen Wrench
101 2 1 Pound Weight
102 1 Weight Rack
103 1 Right Handrail
104 2 Base Cap
105 2 Incline Pivot Nut
106 2 2-lb. Weight
107 1 1/2” Silver Screw
108 1 Audio Wire Nut
109 1 Audio Wire
110 2 Incline Frame Spacer
111 3 Hood Spacer
112 1 Left Handrail
113 1 Edge Guard
114 2 1/2” Spacer
115 4 1” Tek Screw
116 2 Belly Pan Interface
117 4
Weight Rack Bolt
118 2 U-Nut
119 1 5/32 Allen Wrench
120
1
90
°
Screwdriver
# 1 4” Blue Wire, 2F
# 1 User's Manual
* Includes all parts shown in the box
# These parts are not illustrated
To locate the parts listed below, see the EXPLODED DRAWING on pages 29 to 31.
K
ey
No. Qty. Description
K
ey
No. Qty. Description
K
ey
No. Qty. Description
