Key No. Qty. Description
1 2 5/16Ó x 2 1/2Ó Carriage Bolt
2 6 5/16Ó Jam Nut
3 23 5/16Ó Nylon Lock Nut
4 1 Base
5 1 Stabiliser
6 6 3/8Ó Jam Nut
7 6 1/4Ó Nylon Lock Nut
8 21 5/16Ó Flat Washer
9 5 3/8Ó Flat Washer
10 4 1/4Ó Flat Washer
11 10 5/16Ó x 2 3/4Ó Bolt
12 8 3/8Ó x 1 3/4Ó Bolt
13 1 Seat
14 3 5/16Ó x 2 3/4Ó Carriage Bolt
15 6 3 1/2Ó Pulley
16 1 3/8Ó X 3 1/2Ó Bolt
17 1 5/16Ó x 3Ó Bolt
18 8 1/4Ó x 3/4Ó Screw
19 2 Weight Bumper
20 1 Pulley Plate
21 6 3/8Ó Nylon Lock Nut
22 1 1Ó Metal Spacer
23 1 Short Cable
24 2 5/16Ó x 1 1/2Ó Bolt
25 8 Weight
26 1 5Ó Weight Pin
27 3 2Ó Inner Cap
28 1 13 1/2Ó Pad Tube
29 1 Leg Lever
30 2 6Ó Pad
31 1 13Ó Pad Tube
32 2 1 1/2Ó Inner Cap
33 3 5/16Ó x 2 1/4Ó Bolt
34 4 3/4Ó Round Inner Cap
35 1 5/16Ó x 2Ó Eyebolt
36 1 Seat Frame
37 2 Seat Plate
38 2 1/4Ó x 2Ó Carriage Bolt
39 1 Nylon Strap
40 1 Seat Knob
41 1 Backrest
42 1 Front Upright
43 2 1/4Ó x 2 1/2Ó Screw
44 6 1 3/4Ó Inner Cap
45 2 10Ó Pad
46 2 Arm
Key No. Qty. Description
47 2 7Ó Handle
48 4 Handgrip
49 4 1Ó Round Inner Cap
50 2 5 3/4Ó Pad
51 2 1/2Ó x 3/8Ó Spacer
52 1 Arm Frame
53 2 Plastic Bushing
54 4 1Ó Retainer
55 2 1Ó Round Cover Cap
56 2 Large ÒUÓ Bracket
57 1 1 1/4Ó Inner Cap
58 2 Narrow Swivel Bracket
59 4 Cable Trap
60 2 4 1/2Ó ÒLÓ Pin
61 3 5/16Ó x 2Ó Bolt
62 2 3/8Ó x 2 1/2Ó Bolt
63 1 Stop Bracket
64 1 1Ó Plastic Stop
65 2 1/2Ó x 1/2Ó Spacer
66 1 Long Cable
67 1 Top Frame
68 2 Arm Frame Bushing
69 1 Arm Frame Bracket
70 1 3/8Ó x 2 3/4Ó Bolt
71 1 Wide Swivel Bracket
72 2 Weight Guide
73 2 Weight Guide Spacer
74 1 5/16Ó x 6Ó Bolt
75 1 Adjustment ÒUÓ Bracket
76 2 5/16Ó x 3 1/4Ó Bolt
77 4 4 1/2Ó Pulley
78 2 ÒIÓ-Plate
79 1 Weight Tube Bumper
80 1 Weight Tube
81 1 Weight Guide Bracket
82 1 Rear Upright
83 3 Cable Clip
84 1 Chain
85 1 Lat Bar
86 2 Brace
87 1 5/16Ó x 3 1/2Ó Bolt
88 2 2Ó Outer Cap
89 1 Slotted Flange Bushing
# 1 UserÕs Manual
# 1 Exercise Poster
PART LISTÑModel No. WLSI71500 R1200A
Note: Ò#Ó indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the userÕs manual for information about ordering replacement parts.
3
BEFORE YOU BEGIN
ASSEMBLED
DIMENSIONS:
Height: 75 1/2 in.
Width: 55 3/4 in.
Length: 72 in.
Foot Plate
Low Pulley Station
High Pulley Station
Lat Bar
Leg Lever
Arms
Weight Stack
Backrest
Weight Pin
Thank you for selecting the versatile WESLO
¨
BODY
FLEX weight system. The BODY FLEX offers an
impressive array of weight stations designed to devel-
op every major muscle group of the body. Whether
your goal is to tone your body, build dramatic muscle
size and strength, or improve your cardiovascular sys-
tem, the BODY FLEX will help you to achieve the spe-
cific results you want.
For your safety and benefit, read this manual care-
fully before using the BODY FLEX weight system.
If you have additional questions, please call our
Customer Service Department toll-free at 0345-
089009. To help us assist you, please note the product
model number and serial number before calling. The
model number is WLSI71500. The serial number can
be found on a decal attached to the weight sysytem
(see the front cover of this user's manual).
Before reading further, please look at the drawing
below and familiarise yourself with the parts that are
labelled.
