714
9. Press two 1 3/4Ó Inner Caps (44) into each of the
Arms (46).
Apply lubricant to the lower axles on the Arm
Frame (52). Slide a Plastic Bushing (53) and an
Arm (46) onto one of the axles. The upper end of
the Arm must be between the Front Upright (42)
and the bracket on the Arm Frame. Hold two 1Ó
Retainers (54) and a 1Ó Round Cover Cap (55)
against the lower end of the axle. The teeth on the
Retainers must bend toward the Round Cover
Cap. Tap the Retainers and Round Cover Cap onto
the axle.
Attach the other Arm (46) to the Arm Frame (52) in
the same manner.
10. Insert the two 4 1/2Ó ÒLÓ Pins (60) down through
the indicated holes in the Arm Frame (52) and the
Arms (46).
11. Wet the lower ends of the Arms (46) and the
insides of the two 10Ó Pads (45) with soapy water.
Slide a Pad about halfway up each Arm.
Insert a 7Ó Handle (47) with a Handgrip (48) into
one of the Arms (46). Attach the Handle with a 5/16Ó
x 2 1/4Ó Bolt (33), two 5/16Ó Flat Washers (8), a
1/2Ó x 3/8Ó Spacer (51) and a 5/16Ó Nylon Lock Nut
(3).
Attach a 7Ó Handle (47) with a Handgrip (48) to the
other Arm (46).
Press a 1Ó Round Inner Cap (49) into each 7Ó
Handle (47).
9
55
44
60
52
46
47
48
48
47
45
33
8
49
8
45
46
46
3
51
46
46
44
53
Bracket
52ÑLubricate
53
54
44
44
42
54
10
11
ATTACHING THE LEG LEVER TO THE LOW
PULLEY STATION
To use the Leg Lever (29), the seat must be attached
to the Front Upright (42), (see ATTACHING AND
REMOVING THE SEAT on page 13). Attach the Chain
(84) between the Short Cable (23) and the 5/16Ó x 2Ó
Eyebolt (35) on the Leg Lever with two Cable Clips
(83).
ATTACHING THE LAT BAR OR NYLON STRAP TO
THE HIGH PULLEY STATION
Attach the Lat Bar (85) to the Long Cable (66) with a
Cable Clip (83). For some exercises, the Chain (84)
should be attached between the Lat Bar and the Long
Cable with two Cable Clips. Adjust the length of the
Chain between the Lat Bar and the Long Cable so
the Lat Bar is in the correct starting position for
the exercise to be performed.
The Nylon Strap (39) can be attached in the same
manner.
ATTACHING THE LAT BAR OR NYLON STRAP TO
THE LOW PULLEY STATION
Attach the Lat Bar (85) to the Short Cable (23) with a
Cable Clip (83). For some exercises, the Chain (84)
should be attached between the Lat Bar and the Short
Cable with two Cable Clips. Adjust the length of the
Chain between the Lat Bar and the Short Cable so
the Lat Bar is in the correct starting position for
the exercise to be performed.
The Nylon Strap (39) can be attached in the same
manner.
39
39
66
83
84
85
85
23
83
83
84
83
42
84
23
35
29
