1. With the help of a second person, carefully raise the
Uprights (11) until the treadmill is in the position shown.
Cut the plastic tie off the right Upright (11).
11
Tie
ASSEMBLY
Assembly requires two persons. Set the treadmill in a cleared area and remove the packing materials. Do not
dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench
and your own phillips screwdriver , adjustable wrenches , wire
cutters , and needlenose pliers .
Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a
small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This is a normal
condition and does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off
the lubricant with a soft cloth and a mild, non-abrasive cleaner.
2. Inset one of the Extension Legs (34) into the treadmill as
shown. (Note: It may be helpful to tip the Uprights [11] in
the direction shown by the arrow as you insert the
Extension Leg.) Make sure that the Base Pad (40) is on
the bottom of the Extension Leg. Attach the Extension
Leg with an Extension Leg Screw (35). Make sure to
push on the head of the Extension Leg Screw while
tightening it.
Attach the other Extension Leg (not shown) in the same
way.
53
11
2
1
34
40
To Next Page
