8
DIAGRAM OF THE CONSOLE
Clip
Key
Speed Control
Displays
Incline Control
Pulse Sensor
CAUTION:Before operating the
console, read the following precautions.
• Do not stand on the walking belt when turning
on the power.
• Always wear the clip (see the drawing above)
while using the treadmill. When the key is re-
moved from the console, the walking belt will
stop.
• Adjust the speed in small increments.
• The training zones marked beside the speed
control are general guidelines only. See page
14 for more information.
• To reduce the possibility of electric shock,
keep the console dry. Avoid spilling liquids on
the console. Use only a sealable water bottle.
BATTERY INSTALLATION
The console requires three "AA" batteries (not in-
cluded). Alkaline batteries are recommended. To install
batteries, open the battery cover as shown below.
Press the batteries into the battery compartment, with
the negative (–) ends of the batteries touching the
springs. Close the battery cover, push up on the tab,
and then push the tab forward as shown. Make sure
that the tab locks into place.
STEP-BY-STEP CONSOLE OPERATION
If there is a thin sheet of plastic on the console, remove
the plastic. Make sure that the power cord is properly
plugged in (refer to page 7).
Step onto the foot rails of the treadmill. Find the clip at-
tached to the key (see the drawing above), and slide
the clip onto the waistband of your clothes. Next, insert
the key fully into the console. Test the clip by care-
fully taking a few steps backward until the key is
pulled from the console. If the key is not pulled
from the console, adjust the position of the clip as
needed.
Follow the steps on page 9 to operate the console.
Tab
Batteries
Battery Cover
To Next Page
