27
98 1 iFIT Wire
99 1 Upright Grommet
100 1 Allen Wrench
101 5 3/4” Tek Screw
1
02 2 Handrail Endcap
103 1 Power Board Plate
104 4 Base Cap
105 1 Controller Wire
1
06 1 Choke
107 1 Silver Screw
108 2 Static Decal
109 2 Lift Spacer
110 1 Connector Cover
111 1 Hood Spacer
112 2 Bumper
113 1 Edge Guard
114 2 Upright Endcap
115 2 Metal Plate
116 2 Belly Pan Interface
117 2 Rear Foot Spacer
1
18 2 Cup Holder
# 1 Pulse Plate Cover
# 1 8” Blue Wire, 2F
# 1 4” Blue Wire, 2F
#
1 8” White Wire, 2F
# 1 4” White Wire, M/F
# 1 8” Green Wire, 2 Ring
# 1 User's Manual
* Includes all parts shown in the box.
# These parts are not illustrated.
Specifications are subject to change without notice.
1” Tek Screw (56)–4
1
Wheel Nut (15)–2
F
Silver Screw
(107)–1
1 1/2” Screw (79)–4
3/4” Screw (68)–2
4” Bolt (89)–4
Wheel Bolt (86)–2
3” Bolt (47)–4
Star Washer (A)–8
PART IDENTIFICATION CHART
To identify small parts during assembly, use the part identification drawings below.
