PART LIST—Model No. WLTL39304.0 R
0506A
To identify the parts listed below, see the EXPLODED DRAWING in the center of this manual.
1
1 Motor Belt
2 1 Pulley/Flywheel/Fan
3 4 Motor Nut
4* 1 Motor/Pulley/
Flywheel/ Fan
5 1 Incline Motor Bolt
6 2 Incline Motor Spacer
7 1 Incline Motor
8 1 Stop Bracket
9 1 Left Upright
10 1 Right Upright
11 1 Power Supply Bracket
12 1 Frame
13 4 Plastic Standoff
14 1 Warning Decal
15 6 Wheel Nut/
Incline Motor Nut
16 4 Belt Guide Screw
17 1 Wire Harness
18 2 Hood Bracket
19 1 Front Hood Bracket
20 2 Caution Decal
21 1 Reed Switch
22 1 Reed Switch Clip
23 1 Power Supply
24 1 Controller
25 1 Electronics Bracket
26 1 Circuit Breaker
27 1 Power Cord
28 1
Power Cord Grommet
29 10 Washer
30 1 Latch Assembly
31 1 Incline Frame
32 2 Frame Pivot Bolt
33 2 Frame Pivot Spacer
34 1 Tension Bushing
35 1 Front Roller Adj. Bolt
36 1 Foot Rail Cap (Right)
37 1 Motor Tension Nut
38 4 Motor Bolt
39 4 Cap Screw
40 1 Foot Rail Cap (Left)
41
1
Left Foot Rail
42 1 Front Roller/Pulley
43 1 Magnet
44 4 Platform Screw
45 2 Isolator
46 4 Isolator Fastener
47 4 3” Bolts
48 1 Shield
4
9 2 Belt Guide
50 1 Battery Cover
51 1 Front Belly Pan
52 8 U-nut
53 3 Cable Tie Clamp
54 4 Cable Tie
55 1 Walking Belt
56 4 1” Tek Screw
57 1 Rear Roller
58 4 Hood Screw
59 2 Rear Foot
60 1 iFIT Jack
61 1 Ground Wire
62 20 Screw
63 1 Left Rear Endcap
64 1 Right Rear Endcap
65 2 Rear Roller Adj. Bolt
66 1 Motor
67 1 Latch Decal
68 14 Console Screw
69 2 Latch Catch Screw
70 1 Latch Catch
71 1 Walking Platform
72 5 8” Cable Tie
73 1 Incline Bolt
74 1 Motor Tension Bolt
75 2 Right Foot Rail
76 6 3/4” Screw
77 1 Storage Latch Bracket
78 1
Console
79 4 1 1/2” Screw
80 2 Incline Pivot Nut
81 4 Motor Star Washer
82 1 Base
83 2 Incline Frame Bolt
84 2 Motor Tension
Washer
85 2 Handrail
86 2 Wheel Bolt
87 1 Console Base
88 1 Console Crossbar
89 4 4” Bolt
90
1
Key/Clip
91 1 Incline Motor Belly Pan
92
2
Roller Adj. Washer
93
1
Book Holder
94
1
Motor Hood
95
2 Front Wheel
96
1
Incline Motor Shield
97
4
Base Pad
Key
No. Qty. Description
Key
No. Qty. Description
