PART LIST—Model No. WLTL10091 R0501A
Key No. Qty. Description
1 1 Console
2 1 Speed Control
3 1 Key/Clip
4 1 Console Plate
5 17 Screw
6 1 Right Handrail
7 1 Left Handrail
8 1 Battery Cover
9 2 Console Bolt
10 2 Frame Pivot Bolt
11 13 Washer
12 4 Handrail Bolt
13 2 Frame Spacer
14 2 Wheel Bolt
15 2 Wheel
16 2 Base Cap
17 5 Handrail Nut
18 1 Handrail Grommet
19 4 Base Pad
20 4 Belly Pan Screw
21 1 Incline Warning Decal
22 1 Wire Harness
23 1 Hood
24 4 Hood Screw
25 1 Belly Pan
26 4 Small Screw
27 2 Belt Guide
28 2 Roller Spacer
29 2 Wheel Nut
30 1 Circuit Breaker
31 4 Handrail Washer
32 1 Controller Bracket
33 3 Tie Holder
34 4 Plastic Stand-off
35 1 Controller
36 1 Motor Bolt
37 1 Fan
38 1 Motor Tension Nut
39 1 Star Washer
40 1 Motor Tension Washer
41 1 Motor Tension Bolt
42 5 Motor Nut/Frame Pivot Nut
43* 1 Motor Assembly
Key No. Qty. Description
44 1 Pulley/Flywheel
45 1 Motor
46 1 Reed Switch
47 4 Wire Tie Clamp
48 1 Reed Switch Clip
49 1 Magnet
50 1 Belt
51 1 Right Roller Adj. Bolt
52 6 Platform Screw
53 1 Front Roller/Pulley
54 2 Grip Tape
55 1 Frame
56 1 Walking Belt
57 1 Walking Platform
58 2 Incline Leg Bolt
59 4 Ground Screw
60 1 Ground Wire
61 8 8” Cable Tie
62 1 Power Cord Grommet
63 2 Incline Leg
64 2 Incline Leg Nut
65 1 Incline Leg Crossbar
66 2 Roller Adj. Washer
67 2 Frame Endcap
68 4 Endcap Screw
69 1 Roller Tension Bolt
70 1 Roller Tension Nut
71 1 Roller Tension Spring
72 1 Rear Roller
73 1 Releasable Wire Tie
74 1 Allen Wrench
75 1 Latch Warning Decal
76 1 Power Cord
77 1 Storage Latch
78 1 Latch Pin
79 2 Cage Nut
80 1 Base
# 1 8” White Wire, Male/Female
# 1 4” Black Wire, Male/Flag
# 1 User’s Manual
* Includes all parts shown in the box
# These parts are not illustrated
