System Monitor Interface
In the main menu interface, when press or , the inverse cursor
moves between main menu 1 and main menu 2.When the inverse cursor rests at
1．Monitoring in the main menu 1 interface, press to enter into the system
monitoring interface which displays contents as follows. Press or
to circularly display every real-time parameters interface.
▼Solar array voltage and current
The interface shows real-time voltage and current of solar module.
▼ Battery voltage and current
Press to enter into the following interface which shows real-time voltage and
current of battery. Negative indication with current, it means that the battery is in
discharging status. Positive indication with current, it means that the battery is in
charging status.
▼ Battery temperature and battery temperature compensation coefficient
Press to enter into the following interface which indicates real-time
temperature of battery and battery temperature compensation coefficient.
