Charging and Discharging Parameters Setting Interface
In the main menu interface, when press or , the inverse cursor
moves between interfaces of main menu 1 and main menu 2. when the inverse cursor
rests on 3．Parameter Set in main menu 1, press to enter into charging and
discharging parameters setting interface whose displaying interface as follows. When
press , it moves back to the previous interface and the inverse cursor rests on
the position of the first parameter.
﹡
Control voltage setting please in strict accordance with Over Volt. Disc ＞ Charg Lmt＞
Equal ＞ Boost ＞ Float ＞ Boost V. Rect or Under V. Rect ＞ Under V. Warn ＞
Low V. Disc ＞ Discharg Lmt , Please refer to chapter 6 control voltage table while
setting.
▼ Temperature compensation coefficient
Press or , then the inverse cursor moves among every
parameters. When is continuously pressed, the inverse cursor returns to the
main menu. Press or to modify temperature compensation
coefficient.
To Next Page
