31
When save confirmation chosen, the indication of successful saving will occur as follows.
After parameters successfully saved, it returns to main menu interface.
Nominal Parameter Interface
In the main menu interface, when press or , the inverse cursor
moves between the interfaces of main menu 1 and main menu 2. When the inverse cursor
rests on 5．Rated Value in the main menu 1 interface, press and enter into
nominal parameter interface with the following contents displayed. In the interface,
battery type and capacity can be modified and the modification range is 1-999AH. Press
or to modify the relevant parameters.
After confirmed, press and the following picture appears.
Press or to choose save confirmation or save cancellation. After
choosing confirmation, press again, and the modified parameters can be
saved or cancelled. When save cancellation is chosen, the inverse cursor moves back to
To Next Page
