WESTECH VS Series - Page 45

42
* Only suitable for acid battery
Gel
Sealed
Flooded
Charging Parameters
Over Voltage
Disconnect Voltage
Upperlimit
17V; ×2
∕24V; ×4∕48V
Lowerlimit
15V; ×2
∕24V; ×4∕48V
Default
16V; ×2∕24V; ×4∕48V
Charging Limit
Voltage
Upperlimit
16V; ×2
∕24V; ×4∕48V
Lowerlimit
14V; ×2
∕24V; ×4∕48V
Default
15.5V; ×2
∕24V; ×4∕48V
Over Voltage
Reconnect Voltage
Upperlimit
16V; ×2
∕24V; ×4∕48V
Lowerlimit
14V; ×2
∕24V; ×4∕48V
Default
15V; ×2∕24V; ×4∕48V
Equalize Charging
Voltage
Upperlimit
NC
15.2V; ×2
∕24V; ×4∕48V
Lowerlimit
NC
14.2V; ×2
∕24V; ×4∕48V
Default
NC
14.6V ;x2/24V
; ×4
∕48V
14.8V ;x2/24V
; ×4
∕48V
Boost Charging
Voltage
Upperlimit
15V; ×2
∕24V; ×4∕48V
Lowerlimit
13.8V; ×2∕24V; ×4∕48V
Default
14.2V ;x2/24V
; ×4
∕48V
14.4V ;x2/24V
; ×4
∕48V
14.6V ;x2/24V
; ×4
∕48V
Float Charging
Voltage
Upperlimit
14.2V; ×2∕24V; ×4∕48V
Lowerlimit
13.2V; ×2
∕24V; ×4∕48V
Default
13.8V; ×2
∕24V; ×4∕48V
Boost Reconnect
Charging Voltage
Upperlimit
13.5V; ×2
∕24V; ×4∕48V
Lowerlimit
12.7V; ×2∕24V; ×4∕48V
Default
13.2V; ×2
∕24V; ×4∕48V
Low Voltage
Reconnect Voltage
Upperlimit
13.2V; ×2∕24V; ×4∕48V
Lowerlimit
12V; ×2
∕24V; ×4∕48V
Default
12.6V; ×2
∕24V; ×4∕48V
