WESTECH VS Series - Page 46

43
Under Voltage
Warning Reconnect
Voltage
Upperlimit
12.6V; ×2
∕24V; ×4∕48V
Lowerlimit
11.8V; ×2∕24V; ×4∕48V
Default
12.2V; ×2
∕24V; ×4∕48V
Under Voltage
Warning Voltage
Upperlimit
12.4V; ×2∕24V; ×4∕48V
Lowerlimit
11.6V; ×2
∕24V; ×4∕48V
Default
12V; ×2
∕24V; ×4∕48V
Low Voltage
Disconnect Voltage
Upperlimit
11.8V; ×2
∕24V; ×4∕48V
Lowerlimit
10.5V; ×2∕24V; ×4∕48V
Default
11.1V; ×2∕24V; ×4∕48V
Discharging Limit
Voltage
Upperlimit
11V; ×2
∕24V; ×4∕48V
Lowerlimit
10.5V; ×2
∕24V; ×4∕48V
Default
10.8V; ×2
∕24V; ×4∕48V
Equalize Duration
NC
2 hours
Boost Duration
2 hours
Hreshold Voltage Parameters
DTTV (Day Time
Threshold Voltage)
Upperlimit
10V; ×2
∕24V; ×4∕48V
Lowerlimit
1V; ×2
∕24V; ×4∕48V
Default
6V; ×2∕24V; ×4∕48V
NTTV (Night Time
Threshold Voltage)
Upperlimit
10V; ×2
∕24V; ×4∕48V
Lowerlimit
1V; ×2
∕24V; ×4∕48V
Default
5V; ×2
∕24V; ×4∕48V
Temperature Compensation Coefficient
Temperature
Compensation
Coefficient
(TEMPCO)*
-30mV/℃/12V（25℃ ref）
* Compensation of equalize, boost, float and low voltage disconnect voltage.
