Westermo TR-36 - S3 DIP-Switch: Line Speed, Modulation, PLC, Flow Control, Dial

17
6614-2202
S3 DIP-switch
Selection of line speed and modulation
ON
1 2 3 4 5 6 7 8
Use saved parameters
defined by AT+MS
ON
1 2 3 4 5 6 7 8
V.34, 1 9600
ON
1 2 3 4 5 6 7 8
V.21 300
ON
1 2 3 4 5 6 7 8
V.32bis 14400
ON
1 2 3 4 5 6 7 8
V.23 1200 hdx
ON
1 2 3 4 5 6 7 8
V.34 19200
ON
1 2 3 4 5 6 7 8
V.22 1200
ON
1 2 3 4 5 6 7 8
V.34 24000
ON
1 2 3 4 5 6 7 8
V.22bis 2400
ON
1 2 3 4 5 6 7 8
V.34 28 800
ON
1 2 3 4 5 6 7 8
V.32bis 4800
ON
1 2 3 4 5 6 7 8
V.34 33600
ON
1 2 3 4 5 6 7 8
V.32bis, 1 9600
ON
1 2 3 4 5 6 7 8
Automatic line speed
ON
1 2 3 4 5 6 7 8
V.32bis 9600
S3 DIP-switch
Flow control DTE interface
ON
1 2 3 4 5 6 7 8
Use stored value for AT&Kn
ON
1 2 3 4 5 6 7 8
RTS/CTS flow control enable
(AT&K3)
S3 DIP-switch
PLC parameter setting
ON
1 2 3 4 5 6 7 8
Use stored values
ON
1 2 3 4 5 6 7 8
PLC settings
(ATQ1E0&C1&K0&A1)
S3 DIP-switch
Dial abort
S3 DIP-switch
Blind dialing
ON
1 2 3 4 5 6 7 8
Use stored values
ON
1 2 3 4 5 6 7 8
Dial abort disabled (AT&A1)
ON
1 2 3 4 5 6 7 8
Use stored values
ON
1 2 3 4 5 6 7 8
Enable blind dialling (ATX3)
